Steel Palisade Fence

Steel Palisade fence ,which is widely used for Residence, Industrial, Commercial and high-density areas and so on. Powder coated security diplomat fence and heavy duty security gates are far more attractive and pleasing to the eye than conventional chain wire fencing.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Technical Specifications:

Fence Panel Height		1-5m
Fence Width		2.75m, 3m
Pale Height		1.0-5.0m
W Pale width		62mm, 68mm, 70mm, 72mm
D Pale width		65mm
Angle Steel		40*40mm
Pale thickness		1.5-3mm
Top point
Material		Hot and cold steel roll belt, angle steel
Finished		Hot dipped galvanized, polyester powder coated
Powder color		Any RAL series color (Normal RAL6005)
Angle Rail		50mmx50mm, 63x63mm
		Thickness: 4mm-6mm
		Width: 2.75mm and 3.0mm
Post	I beam post	100mmx55mm, height: 1.5m-6m, 150mmx75mm, height:3m-6m
	U post	125x65mm, height:2.5-3.5m
	Square post	70703mm, 80803mm
Material		I beam or square steel pipe or C post
Fish plate		On request or welded onto post
Single arm or double arm		On request
Tension wire or barbed wire		On request
Concertina razor wire		On request
Tension wire		On request
Tie wire		On request
Bolts &nuts		According to need M8x40mm and M12x50mm

Feature of palisade fencing

High strength and high security.
Anti-climb with narrow pale spacing and sharp prongs.
Various colors for perfect aesthetic effect.
Corrosion and rust resistance.
Easy installation and maintenance.
Durable and long service life

Application

School fencing.
Park fencing.
Church fencing.
Stadium fencing.
Residence fencing.
Yard fencing.
Factory fencing.
Farm fencing.
Railway fencing.
Highway fencing.
Road fencing.
Facilities fencing.
Plant fencing.
Construction site fencing.
Development zone fencing.
