Materials: stainless steel wire, iron plate, copper plate, aluminum plate.
Features: good strength-to-weight ratio, wide range of open area percentages, accurate hole sizes, available in corrosion resistant materials, available in lightweight materials, suitable for decorative
applications.
Uses: widely applied to platform, pathway, bridge, trench covers, fences and handrails at systems
of petro-chemicals, urban construction engineering and urban sanitary engineering.
Material : Stainless steel perforated metal-SS304
Hole Diameter | Center Spacing | Thickness | Open area |
0.033" | 0.84mm | 0.055" | 0.0165-0.0198" | 0.40-0.50mm | 28.00% |
0.045" | 1.14mm | 0.066" | 0.0165-0.0198" | 0.40-0.50mm | 37.00% |
1/16" | 1.59mm | 3/32" | 0.026-0.053" | 0.66- 1.35mm | 41.00% |
1/16" | 1.59mm | 1/8" | 0.046-0.053" | 1.17- 1.36mm | 23.00% |
3/32" | 2.38mm | 9/64" | 0.054-0.065" | 1.37- 1.65mm | 40.30% |
3/32" | 2.38mm | 5/32" | 0.026-0.079" | 0.66-2.00mm | 33.00% |
3/32" | 2.38mm | 1/4" | 0.033-0.053" | 0.84- 1.35mm | 12.50% |
1/8" | 3.17mm | 3/16" | 0.026-0.129" | 0.80-2.89mm | 40.00% |
1/8" | 3.17mm | 7/32" | 0.026-0.039" | 0.66-0.99mm | 29.60% |
5/32" | 3.97mm | 3/16" | 0.026-0.065" | 0.66- 1.65mm | 63.00% |
3/16" | 4.76mm | 1/4" | 0.026-0.079" | 0.66-2.00mm | 50.00% |
3/16" | 4.76mm | 5/16" | 0.029", 0.059" | 0.73mm, 1.50mm | 32.00% |
1/4" | 6.35mm | 5/16" | 0.026-0.079" | 0.66-2.00mm | 58.00% |
1/4" | 6.35mm | 3/8" | 0.012", 0.026-0.065" | 0.30mm, 0.66-1.65mm | 40.00% |
1/2" | 12.70mm | 11/16" | 0.059", 0.121" | 1.50mm, 3.00mm; | 48.00% |
Material :Stainless steel metal- SS 316
Hole Diameter | Center Spacing | Thickness | Open area |
0.033" | 0.84mm | 0.055" | 0.016-0.020" | 0.41-0.50mm | 28.00% |
0.045" | 1.14mm | 0.066" | 0.023-0.025" | 0.58-0.64mm | 37.00% |
1/8" | 3.17mm | 3/16" | 0.024", 0.049", 0.121" | 0.61mm, 1.24mm, 3.07mm | 40.00% |
3/16" | 4.76mm | 1/4" | 0.026-0.054" | 0.66- 1.37mm | 50.00% |
3/16" | 4.76mm | 5/16" | 0.098-0.113" | 2.49-2.87mm | 33.00% |
1/4" | 6.35mm | 3/8" | 0.114-0.129" | 2.89-3.28mm | 40.00% |
Material : Galvanized Panel
Hole Diameter | Center Spacing | Thickness | Open area |
3/32" | 2.38mm | 5/32" | 0.029-0.037", 0.046-0.056" | 0.74-0.94mm, 1.17-1.422mm | 33.00% |
3/32" | 2.38mm | 3/16" | 0.029-0.037", 0.057-0.070" | 0.736-0.94mm, 1.45-1.78mm | 25.00% |
1/8" | 3.17mm | 3/16" | 0.023-0.056", 0.114-0.132" | 0.58- 1.42mm, 2.89-3.35mm | 40.00% |
1/4" | 6.35mm | 5/16" | 0.035-0.043" | 0.89- 1.09mm | 58.00% |
1/2" | 12.70mm | 11/16" | 0.046-0.056" | 1.17- 1.42mm | 48.00% |
